Note that in InfoWater Pro junctions, tanks, reservoirs, pumps and valves are modeled as Nodes. Import Element Type: Select the type of element being imported (junction, pipe, valve,reservoir, tank, pump). To open the Import Manager, go to the Model Explorer, click Command Center tab on the bottom, navigate to the Exchange group, and double-click Import Manager. Click Save to save the target file and return to the Export Manager dialog box.Ĭancel:Choose Cancel to delete all changes and Exit out of the Export. Click Browse to bring up the Navigation dialog box. Target File: Choose the location on your network or your hard drive to save the exported file. This option may be used when there is the possibility of duplicate identifiers with other projects. If this box is not checked, no prefix will be inserted. All elements exported will have the Prefix ID inserted before their unique identification. Prefix ID: Only applies to the delimited text option.

The title or the column header will appear in the first row of the exported file. This choice is available only with the Delimited Text option. You may choose the delimiter from among the options below:Ĭreate Field Title (First) Row: Create a field title. For instance, if comma is chosen as the delimiter, commas will be used to separate the different data fields for the elements selected for export. A delimiter can be defined as a data separator.

Format: Choose from a Delimited Text File (comma, tab, etc.), an ESRI Shapefile or a MapInfo MIF/MID format file.ĭelimiter: With the Delimited Text option, select the type of delimiter to use in the export file (tab, comma, etc.) This option is only available when exporting to a Delimited Text file.

Use the Select button to choose on the map display which elements of the project that you want to export.Įxport Options: The options you to specify the type of export file to be created and its destination.

User: N/A: Allows you to graphically select which elements are to be included in the export. The domain option will be available only if a domain has been previously created. The 3 element scope options are as follows:Īll: Automatically selects all elements specified from the project database (regardless of active status).ĭomain: Only those elements currently in a domain are exported. To open the Export Manager, go to the Model Explorer, click the Command Center tab on the bottom, navigate to the Exchange group, and double-click Export Manager.Įxport Element Type: Select the type of element for which an export file is to be created (junction, pipe, valve,reservoir, tank, pump).Įlement Scope: The element scope is used to create the elements made available for an export.

InfoWater Pro Import Manger allows you to quickly bring in the external data in the shape file format, text file format, or. InfoWater Pro Export Manager allows you to quickly export the hydraulic model data to an external file in the shape file format, text file format, or.
